Scrap copper wire recycling machine

Copper wire recycling machine is mainly used to make the double recycling use of metal and plastics from scrap wires. The copper wire recycling machine through crude crushing to extract the iron materials, then through fine crushing to separate the metal and plastic mixture.

+86-135-2669-2320

market@doinggroup.com

Send Message Chat Online

Features

Copper wire recycling machine is mainly used to make the double recycling use of metal and plastics from scrap wires. The copper wire recycling machine through crude crushing to extract the iron materials, then through fine crushing to separate the metal and plastic mixture.Since the plastic and metal granules are uniform, but the weight has big difference, they are easy to be separated by the gravity separator. But the plastics after separated by the gravity separator is not completely clean, may have about 2or5% small copper wre or powder. Then use the electrostatic separator can extract the rest and small copper wire or powder out to get pure plastic and copper metal. Thus to increase the recycle use value of the plastics and metals.

copper recycling machine
Copper wire recycling machine



1. Suitable structure and layout, easy to install.
2. PLC system makes it easier to control the whole line, convenient to feed and operate.
3. The design of separator and dust collector is handy for movement or transport.
4. The rotor of the grinder is alternating, leading to more efficiency, faster discharging, low noise and steadier running.
5. Feedback system will do the second crushing to the unfinished material, which guarantees the total separation of metal and non-metal.
6. The separation rate of air separator can reach at least 99%.
7. Dust collector can prevent the leak of dust. The dust cleaning rate can reach 99.99%.


Technical Data

Copper wire recycling machine technical data

Model  Voltage  Power  Capacity Dimension    Weight
DYTM-400   380V    22.45 kw    150-200kg/H      2700*1900*2300(mm)   1200kg
DYTM-600 380V  36 kw 300-400kg/H 3500*1900*2700(mm) 3000kg
DYTM-800 380V  75 kw 500-600kg/H 5500*4500*3300(mm) 8000k



Application

Copper wire recycling machine application

wire recycling machine

Application of copper wire recycling machine

Copper wire recycling machine can application to all kinds of scrap wires, copper wire, aluminium wire, such as automobile electric line, motorcycle electric line, storage battery electric line, waste household appliance disassembly electric line, electromechanical equipment disassembly electric line, computer cable, telephone wire, cable TV line, communication cable and other scrap wires which are difficult to recycle, circuit board, copper-clad plate, etc
