Waste tyre recycling plant price

On the basis of pyrolysis technology, Doing group has manufactured the leading eco-friendly and cost-effective waste tyre recycling plant . This waste tyre recycling plant can effectively convert waste tyres into tyre oil, carbon black and s...

tyre recycling plant
Waste tyre
Waste tyre pollution problem has been disturbing us for a long time. Today, there emerges a new way recycling used tyres which is called pyrolysis. Pyrolysis basically involves the thermal decomposition of the tire at high temperatures (300–900°C) in an oxygen-free atmosphere. It is proved to be an ideal technology to solve tyre and other kinds of solid wastes which are becoming the serious issues nowadays.
tyre recycling plant price
Waste tyre recycling plant price
On the basis of pyrolysis technology, Doing group has manufactured the leading eco-friendly and cost-effective waste tyre recycling plant . This waste tyre recycling plant can effectively convert waste tyres into tyre oil, carbon black and steel wire. The carbon black from tyre pyrolysis can be used for making construction bricks with clay, also can be used as fuel.

Waste tyre recycling plant price feature
tyre recycling plant price
Waste tyre recycling plant price installed in different countries
1.We can get tyre oil,carbon black,and steel from waste rubber tires and plastics.
2. High oil output rate 45%-55%, the rubber up to 60%.
3. Rapid condenser, we have 5 condensers, the cooling area up to 53 square meters, the area larger, the more oil u can get.
4. Large capacity: 6tons / 8tons / 10tons / 12tons / 20tons.
5. Safety device, we have automatic alarm bells with pressure gauge, If pressure gauge more than the pressure, bells will ring.
6. Environmental protection, no pollution, no smell.
7. 6—8 years life, 3 years warranty



Waste tyre recycling plant price technical data

Technical parameter of Waste tyre recycling plant price
No. Items Contents
1 Equipment type DY-1-6 DY-1-8 DY-1-10
2 Raw material Waste tire Waste tire Waste tire
3 Structural form Horizontal rotation Horizontal rotation Horizontal rotation
4 24-hour Capacity 6 ton 8 ton 10 ton
5 Oil yield 2.7-3.3ton 3.6 -4.4ton 4.5 -5.5ton
6 Operating pressure Normal Normal Normal
7 Material of pyrolysis Reactor Q245R Q245R Q245R
8 Thickness of pyrolysis Reactor 16mm 16mm 16mm
9 Rotate speed of pyrolysis Reactor 0.4turn/minute 0.4turn/minute 0.4turn/minute
10 Total power 19KW 19KW 19KW
11 Mode of cooling Water cooling Water cooling Water cooling
12 Cooling area of condenser 100sqm 100sqm 100sqm
13 Kind of transmission Internal gear drive Internal gear drive Internal gear drive
14 Noise dB(A) ≤85 ≤85 ≤85
15 Size of Reactor(D×L) 2200×6000 2200×6600 2600×6600
16 Working form Intermittent operation Intermittent operation Intermittent operation
17 Delivery time 20days 20days 20days
18 Weight 27T 30T 35T

Prepared by customer about waste tyre  recycling plant
No. Item Consumption
1 Coal(for choice) 500kg/day
2 Wood(for choice) 800kg/day
3 Natural gas(for choice) 100-150kg/day
4 Oil(for choice) 300-350kg/day
5 Electricity 244kwh/day
6 Water(recycled) 60㎥ /month
7 Total power 19kw
8 Land area 35m*15m


Waste tyre recycling plant price final product application

Waste tyre recycling plant price of Doing can get Fuel oil (45% to 52%) ,Carbon black (30% to 35%) ,steel wire (12%-15%),this product can use widely in inductries.
tire recycling plant
Fuel oil application
