advantages of doing brand pyrolysis plant

Pyrolysis Plant

Pyrolysis plant is mainly to convert the waste plastic or tyre into crude oil for fuel.Recently years the technology pyrolysis plant is consistently developing.From the plant to the final product of the pyrolysis plant. Many aspects of the pyrolysis plant are advancing. We henan doing mechanical equipment co,ltd made many innovations of the pyrolysis plants. pyrolysis plant is fast developing under the time of sustainable development. And the pyrolysis technology will surely be popular in the future.

Chat Online Leave A Message
Pyrolysis plant is mainly to convert the waste plastic or tyre into crude oil for fuel.Recently years the technology pyrolysis plant is consistently developing.From the plant to the final product of the pyrolysis plant. Many aspects of the pyrolysis plant are advancing. We henan doing mechanical equipment co,ltd made many innovations of the pyrolysis plants. pyrolysis plant is fast developing under the time of sustainable development. And the pyrolysis technology will surely be popular in the future.

The plastic/tyre to oil pyrolysis plant which has been improved has the advantages as follow:
  1. First we need professional technicians to install the plant. The new designed auto-feeding system will put the material into the reactor automatically. Thus will improve the efficient and make the reactor safer. With auto feeding, The indirect heat system will prevent the reactor from blast and will enlarge the area of heating.
  2. When we burn the reactor we will use wood,coal,or oil gas. the heat fuel is only used on start-up to heat the reactor, wnen the reactor can generate oil gas. our pyrolysis plant will be heated with its own oil gas. That means just little energy is required to heat the reacor.
  3. the oil gas will go into the condenser. The condenser is used to cool the oil gas into liquid. Inside the condenser there are 57 cooling pipes with diameter 48mm each inside the condenser,which means the cooling area of each condenser is 13 m2. Take the 10T capacity for example, there are 5 condensers ,so the total cooling area can reach 65 M2  Therefor the oil yield rate is guaranteed.Then there are two horizontal condensers for our 5th generation pyrolysis machine. its inner structure is similar with that of vertical condenser.however,the cooling area of one horizontal condenser can be equal to more than three vertical condensers. And also,the cooling way is longer than vertical condenser.In this way,there will be a better oil output.
Technical parameter of 5th generation waste tire/plastic recycling machine
  Items Contents
1 Equipment type DY-1-6 DY-1-8 DY-1-10
2 Raw material Waste tyre Waste tyre Waste tyre
3 Structural form Horizontal rotation Horizontal rotation Horizontal rotation
4 24-hour Capacity 6 ton 8 ton 10 ton
5 Oil yield 2.7-3.3ton 3.6 -4.4ton 4.5 -5.5ton
6 Operating pressure Normal Normal Normal
7 Material of pyrolysis Reactor Q245R Q245R Q245R
8 Thickness of pyrolysis Reactor 16mm 16mm 16mm
9 Rotate speed of pyrolysis Reactor 0.4turn/minute 0.4turn/minute 0.4turn/minute
10 Total power 19KW 19KW 19KW
11 Mode of cooling Water cooling Water cooling Water cooling
12 Cooling area of condenser 100sqm 100sqm 100sqm
13 Kind of transmission Internal gear drive Internal gear drive Internal gear drive
14 Noise dB(A) ≤85 ≤85 ≤85
15 Size of Reactor(D×L) 2200×6000 2200×6600 2600×6600
16 Working form Intermittent operation Intermittent operation Intermittent operation
17 Delivery time 20days 20days 20days
18 Weight 27T 30T 35T



Technical parameter of waste tire recycling plant
  Items Contents
1 Equipment type DY-1-6
2 Raw material waste tyre
3 Structural form Horizontal rotation
4 24-hour Capacity 6 ton
5 Oil yield 2.7-3.3ton
6 Operating pressure Normal
7 Material of pyrolysis Reactor Q245R
8 Thickness of pyrolysis Reactor 16mm
9 Rotate speed of pyrolysis Reactor 0.4turn/minute
10 Total power 19KW
11 Mode of cooling Water cooling
12 Cooling area of condenser 100sqm
13 Kind of transmission Internal gear drive
14 Noise dB(A) ≤85
15 Size of Reactor(D×L) 2200×6000
16 Working form Intermittent operation
17 Delivery time 20days
18 Weight 27T
The waste tyre pyrolysis plant is used to convert the waste tyre  into fuel oil,it is good machine to deal with the waste tyres,waste plastics.
The pyrolysis oil extracted from waste tyre pyrolysis plant is mainly used in glass factory,cement factory,steel factory etc.
