Doing pyrolysis of plastics waste is a new green technology to recycle plastic and Doing have applied this technology in automatic anc continuous waste tire plastic pyrolysis plant. By using the Automatic and continuous waste tire plastic pyrolysis plant, finally you can get these pyrolysis products, such as fuel oil, carbon black and some combustible gas, all of which have a wide range of applications.
Automatic and continuous waste tire plastic pyrolysis plant is the new design of pyrolysis plant.Compared to batch pyrolysis plant. Automatic and continuous waste tire plastic pyrolysis plant can run automatically and continuously. It will help you to save much time and labor during operation. You only need to feed raw materials into the reactor every few hours. The automatic and continuous waste tire plastic pyrolysis plant itself will help you to collect oil into tank and slag the carbon black powder.
In order to guarantee safety, energy saving and environmental protection in the whole pyrolysis process, the automatic and continuous waste tire plastic pyrolysis plant is also equipped with advanced safety devices (alarm for over temperature and pressure, auto pressure releasing system, fire fighting devices) and strong spray dedusting system (water spray, ceramic ring filter, washing chamber).
Automatic and continuous waste tire plastic pyrolysis plant technical data
No. | Item | Specifications | ||||||
1 | Model | DY-C-10 | DY-C-20 | DY-C-30 | DY-C-50 | DY-C-60 | DY-C-80 | DY-C-100 |
2 | Cpacity | 10T/D | 20T/D | 30T/D | 50T/D | 60T/D | 80T/D | 100T/D |
3 | Power | 35Kw | 50Kw | 65Kw | 80Kw | 90Kw | 105Kw | 120Kw |
4 | Working type | Continuous | ||||||
5 | Reactor deisgn | Mutiple reactors (The quantity and size depends on the raw material condition) | ||||||
6 | Rotating | Internal rotating | ||||||
7 | Cooling system | Recycled waster cooling | ||||||
8 | Reactor material | Q245R/Q345R boiler plate | ||||||
9 | Heating method | Indireact hot air heating | ||||||
10 | Heating fuel | Fuel oil/gas | ||||||
11 | Feedstock | Waste tire/plastic/rubber | ||||||
12 | Output | Fuel oil, carbon black |
Automatic and continuous waste tire plastic pyrolysis plant final product and application
NO | Name | Percentage | Usage |
1 | Tire /plasticoil | 45% | 1.Can be sold directly 2.Can be as fuel 3.Can be used industrial and commercial purposes. Such as power plant factory,glass factory,cement factory,ceramic factory. |
2 | Carbon black | 30% | 1.Can be sold directly 2.Can be used electric cable jacketing,black nylon bag,rubber additive |
3 | Steel wire | 15% | 1.Can be sold directly 2.Make steel bloom by use hydraulic press-packing |
4 | Oil gas | 10% | 1.Can be as fuel burn by use gas burning system 2.Extra gas also be storage as fuel for other heating |
