Used of plastic waste recycling machine

Nowadays, many people advocate the “Green” living, which is approved many people. So it is better to shred, melt and repurpose all these plastic materials instead of throwing away the waste plastic to pollute the environment.

Therefore,Doing makes great efforts to develop and manufacture the used of plastic waste recycling machine, which is very popular after it comes into being. The used of plastic waste recycling machine is a great recycling machine which is can be widely applied to large-scale, large-volume recycling of post-consumer, post-commercial, and post-industrial plastic scrap. The Used of plastic waste recycling machine is mainly used to reprocess plastic and make the material reusable for another product.

Used of plastic waste recycling machine

Easy operation: It has automatic constant temperature control and stable performance. After adjusting well, one or two workers are enough to operate this machine, to feed the materials and change pellet receiver.

Low cost after redesign: Now this kind machine is more economic in electric power source and also water. In the long working life of this machine, it can save many sources in energy.

High output, long operating life and lower noise: It’s the ideal waste plastics regenerative pelletizer machine nowadays.

Energy and space saving: Doing waste plastic recycling equipment combines shredding, extruding and pelletizing into one machine and uses the high torque gearbox with precise grinding.

Features
Technical Data
Application

Used of plastic waste recycling machine technical

Technical parameter of used of plastic waste recycling machine
No.	Items	Contents
1	Equipment type	DY-1-6	DY-1-8	DY-1-10
2	Raw material	Waste plastic	Waste plastic	Waste plastic
3	Structural form	Horizontal rotation	Horizontal rotation	Horizontal rotation
4	24-hour Capacity	6 ton	8 ton	10 ton
5	Oil yield	2.7-3.3ton	3.6 -4.4ton	4.5 -5.5ton
6	Operating pressure	Normal	Normal	Normal
7	Material of pyrolysis Reactor	Q245R	Q245R	Q245R
8	Thickness of pyrolysis Reactor	16mm	16mm	16mm
9	Rotate speed of pyrolysis Reactor	0.4turn/minute	0.4turn/minute	0.4turn/minute
10	Total power	19KW	19KW	19KW
11	Mode of cooling	Water cooling	Water cooling	Water cooling
12	Cooling area of condenser	100sqm	100sqm	100sqm
13	Kind of transmission	Internal gear drive	Internal gear drive	Internal gear drive
14	Noise dB(A)	≤85	≤85	≤85
15	Size of Reactor(D×L)	2200×6000	2200×6600	2600×6600
16	Working form	Intermittent operation	Intermittent operation	Intermittent operation
17	Delivery time	20days	20days	20days
18	Weight	27T	30T	35T

Prepared by customer about used of plastic waste recycling machine
No.	Item	Consumption
1	Coal(for choice)	500kg/day
2	Wood(for choice)	800kg/day
3	Natural gas(for choice)	100-150kg/day
4	Oil(for choice)	300-350kg/day
5	Electricity	244kwh/day
6	Water(recycled)	60㎥ /month
7	Total power	19kw
8	Land area	35m*15m

Features
Technical Data
Application

Used of plastic waste recycling machine final product application

Fuel oil from used of plastic waste recycling machine used in below industries

Fuel oil application

A.Power plant factory
B.Glass factory
C.Cement factory
D.Ceramic fatory
E.Aluminum factory
F.Boiler factory
G.Central heating factory
H.Painting factory

Carbon black application

Carbon black from used of plastic waste recycling machine
A.Electric cable jacketing
B.Conveyor ban
C.Hose and doormat
D.Black nylon bag
E.Rubber additive
F.Automatic spare parts
G.Heat isolation
H.Black colorant in rubber materials
