China environmental friendly pyrolysis plant manufacturer

Traditional soil stove not only severely damages the ecological environment, disturbs the market order, but also places serious safety hazards on the lives and property safety of the surrounding people.DoingGroup pyrolysis plant can solve all of the problems and bring you higher oil yield!!

traditional soil stove
Traditional soil stove


Traditional soil stove not only severely damages the ecological environment, disturbs the market order, but also places serious safety hazards on the lives and property safety of the surrounding people. This issue has caused the public security law enforcement agencies in our country to attach great importance to this phenomenon.

traditional soil stove is unlawful
Troditional soil stove is u
nlawful

At present, there are already many troditional soil stoves under the high pressure of the law enforcement agencies and they are subject to relevant legal sanctions.
Due to environmental issues, corresponding documents have been issued at  this year's two important political sessions to emphasize the importance of environmental protection for the national economy and people's livelihood.

pyrolysis plant
DoingGroup's pyrolysis plant


Under this situation, what kind of oil pyrolysis plant should we choose to comply with the development of national policies without affecting our normal equipment operation?
On the one hand,The DoingGroup's waste plastic/tire pyrolysis plant is much higher than the traditional soil stoves due to the tightness of the oil output. On the other hand, DoingGroup's waste plastic/tire pyrolysis plant is in the R&D design stage. Taking into account that the waste generated by combustion, waste water, and waste residue can cause pollution to the environment,   its environmental protection from the following aspects.
Wastewater pollution control
The company's waste tire pyrolysis plant production line, whether it is cooling water or dedusting water all use recycled water, to ensure that the production process to achieve zero discharge of wastewater.
(1) Cooling water
Column tube condenser design, the pipeline to go oil, pipe outside the water. Water and oil are in zero contact, and the cooling water can be recycled without emissions. Both environmental protection and increased cooling area, so that oil and gas can be fully cooled.

dedust waster system
DoingGroup enviromental protection dedust waster system
(2) Dedusting water
The machine is equipped with a professional water film dust remover. Three-layer high-pressure spray technology can fully clean solid particles in smoke.
(3) High efficiency dry dedusting
If the fuel is coal, firewood or heavy oil, the amount of smoke is large, you can also choose to use pulse dust removal device. Dry dedusting does not require water and does not produce any water contamination.
Waste gas pollution control
The exhaust gas mainly comes from the exhaust gas generated during the oil pyrolysis plant production process. Under normal circumstances, the exhaust gas can be directly recycled to heat the tire pyrolysis reactor to save other fuels.
The smell of smelly chicken eggs produced in the exhaust gas will cause air pollution when discharged into the air, and the harmful gas to the human body will help the customer to completely solve the problem of factory odor by the company's desulfurization and deodorization tower system.Got the unanimous praise.
Waste residue pollution control
The carbon black residue generated during the combustion process is automatically discharged outside the furnace through the company's underground sealed slag discharge system. Due to better sealing, secondary pollution of the air caused by the waste residue during the discharge process can be avoided.

Responding to the national call to protect our enviromental, DoingGroup is your best choice ,investing in oil pyrolysis plant!




Technical parameter of DoingGroup pyrolsysi plant
No. Items Contents
1 Equipment type DY-1-6 DY-1-8 DY-1-10
2 Raw material Waste tyres Waste tyres Waste tyres
3 Structural form Horizontal rotation Horizontal rotation Horizontal rotation
4 24-hour Capacity 6 ton 8 ton 10 ton
5 Oil yield 2.7-3.3ton 3.6 -4.4ton 4.5 -5.5ton
6 Operating pressure Normal Normal Normal
7 Material of pyrolysis Reactor Q245R Q245R Q245R
8 Thickness of pyrolysis Reactor 16mm 16mm 16mm
9 Rotate speed of pyrolysis Reactor 0.4turn/minute 0.4turn/minute 0.4turn/minute
10 Total power 19KW 19KW 19KW
11 Mode of cooling Water cooling Water cooling Water cooling
12 Cooling area of condenser 100sqm 100sqm 100sqm
13 Kind of transmission Internal gear drive Internal gear drive Internal gear drive
14 Noise dB(A) ≤85 ≤85 ≤85
15 Size of Reactor(D×L) 2200×6000 2200×6600 2600×6600
16 Working form Intermittent operation Intermittent operation Intermittent operation
17 Delivery time 20days 20days 20days
18 Weight 27T 30T 35T

Prepared by customer about DoignGroup pyrolysis plant
No. Item Consumption
1 Coal(for choice) 500kg/day
2 Wood(for choice) 800kg/day
3 Natural gas(for choice) 100-150kg/day
4 Oil(for choice) 300-350kg/day
5 Electricity 244kwh/day
6 Water(recycled) 60㎥ /month
7 Total power 19kw
8 Land area 35m*15m


China environmental friendly pyrolysis plant manufacturer plant final product  application

Fuel Oil (40% to 45%)

pyrolysis plant fuel oil usage
Fuel oil application

The main oil product produced by our recycling application is the fuel oil that is wide used for industrial and commercial purposes. The oil has 40% to 45% of the amount of recycled scrap tyres, which will be carried with licensed tanker trucks.

Carbon Black Powder (30% to 35%)

pyrolysis plant carbon black usage
Carbon black application


The second product of waste tyre pyrolysis processs plant is carbon black. The quantity of carbon black is about 30% to 35% according to tyre quality. The use of carbon black is as a chemical strengthener in rubber and coloring agent in pigment industries. This carbon black price is very competitive compare to petroleum carbon black, so our pyrolysis carbon black is good option in stead of petroleum carbon black.

Steel Wire Scrape ( 10% TO 15% )
The third product of waste tyre pyrolysis process plant is steel wire, the quantity of steel wire is about 10% to 15% according to tyre quality. Its very easy to sales steel wire scrape in local market.

Pyrolytic Gases ( About 10 % )

We get pyrolytic gases during process about 10% of waste tyre. The main component of this gases are methane ( CH4 ), so we can not condense and store this gases. We use this gases to heat the reactor and we can use exceed gases for other heating application.
